Uniview UAC-B112-F40 Bullet Camera

Technical specifications

Camera form

Bullet

Resolution

2MP

Lens

4mm

Night vision

20m IR

IP rating

IP67

Power

12V DC

Image sensor

1/3" 2 MP progressive CMOS

Max. resolution

1920 x 1080

Min. illumination

0.02 Lux @ F2.0 (AGC on); 0 Lux with IR

Shutter time

PAL 1/25-1/50,000 s; NTSC 1/30-1/50,000 s

Day & night

IR-cut filter (ICR); auto, day and night modes

Field of view

4.0 mm: H 80.2° / V 40.7° / D 90.5°

Supplement light

IR, up to 20 m (≥ 60,000 h)

Frame rate

TVI/AHD/CVI 1080p at 25/30 fps; CVBS PAL/NTSC

Wide dynamic range

DWDR

Image enhancement

2D DNR; BLC, HLC, DWDR; auto/manual white balance

Material

Plastic

Dimensions

142 x 63 x 65 mm

Weight

135 g

Operating conditions

-30 °C to 60 °C, humidity ≤ 95% RH (non-condensing)

Approvals

CE-EMC, FCC Part 15B, CE-LVD (EN 62368-1), CE-RoHS/WEEE; IP67
